PRODUCT APPLICATION:
FEATURES:
| PLC | With 7-inch Color Touch Screen |
| Temperature Control | PID Temperature Controllers |
| Pneumatic | Festo / Comozzi |
| Electronic Sensor | Omron / Sick |
| Electronic Components | Schneider |
| Indication | Tower Light Indication |
| Safety | Emergency Stop |
| Covering | Stainless Steel Covering |
| Maintenance | Low Maintenance |
TECHNICAL SPECIFICATIONS:
| Sealing type | Center seal / 3 side seal / 4 side seal with batch cutting (Pneumatic Intermittent Operated) |
| Filling System / Range | Pneumatic Operated Pump / 5 ml to 100 ml |
| Machine Speed | 20-70/Min. (Depending upon Pack Size) |
| Main Motor | 0.5 hp for Paper Pull and 50 watt DC motor for Unwinding System |
| Heaters | 200 watt 2 pcs / 250 watt – 2 pcs |
| Laminate | Heat sealable laminate film. Core Dia – 75mm / Max Outer Dia 350mm |
| Machine Dimension | 1000(L) X 1000(W) X 2000(H) mm |
| Machine Weight | 400-450 Kg Approx |
| Optional Attachment | Out feed Conveyor, TTo Printer |
| Air Compressor | 6 CFM |
