PRODUCT APPLICATION:
FEATURES:
| Sachet Forming | Sachet forming & sealing device with any one selected width of former |
| Control Panel | Electronic control panel with interlocking system, PID for vertical & horizontal sealing, sachet counter, rotary switch with indication lamps, applicable relays, contractors, VFD drive, flexible wire completely housed inside the machine |
| Scanner | Scanner for correction of eye mark in the printed heat sealable laminated film |
| Product Contact Parts | All product contact parts in SS-304 |
| Product Handling | The product is fed in the conveyor by the operator, the pusher automatically collects the product and moves it horizontally to the tube forming device where cross sealing and the cutting knife separates the packed pouches |
TECHNICAL SPECIFICATIONS:
| Sealing type / system | Center seal / Continuous Heat seal |
| Machine Speed | 80-200/Min (Depending upon Pack Size) |
| Main Motor | 0.5 hp for Paper Pull, 1 hp for Telescopic Cup Filler (All motors are AC Motors with gear box) |
| Laminate | Heat sealable laminate film. Core Dia – 75mm / Max Outer Dia 350mm |
| Optional Attachments | Ink Jet / TTO Printer |
| Contact Parts | SS304 |
