PRODUCT APPLICATION:
FEATURES:
| PLC | With 7-inch Color Touch Screen |
| Temperature Control | PID Temperature Controllers |
| Pneumatic | Festo / Comozzi |
| Photocell Sensor | Photocell Control Teaching Sensor |
| Filling System | Auger with Servo Motor for Weight Accuracy |
| Packaging Operation | Designed to perform Pillow / Gusset type Packaging |
| Safety & Indication | Emergency Stop / Tower Light Indication |
| Covering | Stainless Steel Covering |
| Nitrogen Flushing | Included |
| Maintenance | Low Maintenance |
TECHNICAL SPECIFICATIONS:
| Sealing type | Center seal / 3 side seal (Pneumatic Intermittent Operated) |
| Filling System | Counting Base |
| Filling Range | 1-50 Cone count capacity (Depends on Application) |
| Machine Speed | 20-40/Min (Depending upon counts) & 5-30 Packets/Min (Depending upon counts) |
| Main Motor | 0.5 hp for Paper Pull and 50 watt DC motor for Unwinding system |
| Heaters | 150 watt 2 pcs./ 250 watt – 2 pcs |
| Laminate | BOPP Heat sealable laminate film. Core Dia – 75mm / Max. Outer Dia 350mm |
| Power/Power Consumption | 220 Volt / 50 Hz / 2.5KW |
| Machine Dimension | 1800(L) x 1500(W) x 1550(H) mm |
| Machine Net Weight | 500-600 Kg Approx |
| Air Compressor | 6 CFM |
